Technical Specs Brochure Warranty File Description Our Micro Chill Series offers compact chillers available in 3 HP, 5 HP and 7 HP to cover the range of needs in smaller process cooling applications. With an oversized stainless steel reservoir and heavy duty process pump with built-in fluid dynamic bypass valve, these compact chillers provide precise cooling with the same quality components as their larger siblings, but in a more compact design with an equally compact price. Key Specs (WxLxH): 32” x 52” x 40” Tank Volume: 30 Gallons Process Pump: 0.75 HP GPM @ 25PSI: 25 GPM Operating Weight: 900 lbs Connection Size: 1" Request A Quote Features Complete refrigeration circuit Engineered high efficiency heat exchanger for maximum energy savings Glycol pump Dynamic fluid bypass valve Insulated stainless steel glycol reservoir with level indicator All insulated copper piping High and low pressure controls Freeze stat safety switch High temp alarm Low ambient control Anti-cycle timer to prevent short cycling of compressor On/pump down/off switch Single stage digital temperature controller for simple operation Fully powder coated steel frame Powder coated aluminum housing Louvered access panels for easy service and maintenance Factory run tested and fully charged with refrigerant Two year parts and one year labor warranty ETL 508A listed complete control panel with single point electrical connection, breakers, starters & safety switches One year free remote monitoring subscription Single Stage ChillersSelect ModelsSingle Stage air cooled chillers are built with a compact, but rugged platform that is simple to operate and easy to maintain. Every Single Stage packaged chiller incorporates a single compressor design.GD – 1.5H Nano ChillGD – 2H Nano ChillGD – 3H Micro ChillGD – 5H Micro ChillGD – 7H Micro ChillGD – 10H Micro ChillGD – 13.5H Micro Chill
